driver and a virtual COM port driver that makes the USB port look and perform like a physical
COM port. After the modem is detected, a wizard for installing the USB driver is launched.
To install the two USB drivers:
1. Go to ftp://ftp1.digi.com/support/documentation/XBP_ZB_Programmable_DK/ and
download the driver that matches your operating system. Save the file on your Desktop or
other designated area. Extract the files to another folder for future use.
2. Plug in the Digi XStick [Fig 1]. The Found New Hardware Wizard dialog box will load.
XStick
Figure 1: XStick setup
3. Select Install from a specific list or location (Advanced) ; then click Next .
4. Select Include this location in the search . Browse to where you saved the WINDOWS
drivers folder.
5. Click Next . If a hardware installation Windows alert box pops up click Continue Anyway .
6. Click Finish .
You may be prompted to install another driver, the virtual COM port driver. Repeat steps 5 and
6 to install this driver.
Step 3: Download and Install Compiler
The XBee-PRO ZB programmable module has a microprocessor that can run custom
applications. The microprocessor is a Freescale? MC9S08QE32CFT. To develop applications
on this processor you must have the software tool CodeWarrior? from Freescale.
1. Go to Digi’s ftp site:
ftp://ftp1.digi.com/support/documentation/XBP_ZB_Programmable_DK/
2. Right-click on CW_MCU_V6_3_SE.exe and choose Save Target As… to save to your PC
for installation.
Note: This is a large file and may take 30 minutes or more to download depending on
your connection speed.
3. Double-click on the .exe file and click Run .
2
